ucsunly，60V 3.5kW/4kW/5kW golf cart; electric off-road; hot-selling electric golf trolley
PRODUCT PARAMETERS |
UCA Golf Cart DH-13 | Off-Road A Model | Forward-Facing Double-Row 4 Seats |
System | Item | Specification |
ELECTRICAL SYSTEM | ||
Electrical System
| Controller | 60V / 72V fully intelligent electric controller |
Battery | 120Ah lithium battery (battery capacity can be upgraded) | |
Motor | 3.5 kW / 4 kW / 5 kW AC motor | |
Charger | On-board intelligent charger | |
Charging Time | 6-8 hours (at 80% depth of discharge) | |
Charging Input Voltage | 220V / 110V | |
TECHNICAL PARAMETERS | ||
Technical Parameters | Maximum Driving Speed | 25 km/h |
Maximum Gradeability | 15% | |
Braking Distance | ≤ 5 m | |
Minimum Turning Radius | 4 m | |
Minimum Ground Clearance | 400 mm | |
Overall Dimensions (L × W × H) | 3250 × 1250 × 1900 mm | |
Driving Range | Depends on battery capacity | |
Wheelbase | 2350 mm | |
Rated Passenger Capacity | 4 persons | |
Track Width (Front/Rear) | 990 / 1000 mm | |
Curb Weight | 580 kg | |
BODY SYSTEM | ||
Body System | Seats | Bench seats (leather upholstery + high-resilience PU seats); seat style and color can be customized |
Body | Steel frame + injection-molded shell / ABS engineering plastic molded parts | |
Instrument Panel | Instrument display (including voltage display) | |
Rearview Mirrors | Manual exterior rearview mirrors | |
Lighting & Signals | LED combined headlights, turn signals, combined rear taillights, brake lights, electric horn | |
Switches | Start switch, light switch, forward/reverse gear switch | |
Frame | Steel structure frame | |
Steering Wheel | Polyurethane foam steering wheel | |
CHASSIS SYSTEM | ||
Chassis System | Power Transmission System | Rear drive, stepless speed control system |
Steering System | Rack-and-pinion steering gear | |
Front Axle & Suspension | Semi-floating front axle | |
Rear Axle & Suspension | Integral rear axle + high-strength steel leaf spring + hydraulic cylinder shock absorber | |
Braking System | Four-wheel drum hydraulic brakes, dual-circuit hydraulic braking, parking brake device | |
Wheels | 12-inch tubeless radial tires with aluminum alloy rims | |
Configurations can be customized according to order requirements.
